Reclaimed Wafer & Wafer Thinning

IGBT-BGBM

再生晶圓與晶圓薄化

IGBT-晶背減薄與金屬化

Silicon / SiC / GaN

  • 再生晶圓以物理除膜技術,減少設備投資,更能減降環保負荷與生產成本。

  • 晶圓薄化超薄研磨 (≥50um) ⾼良率产出,創新蝕刻製程,作應力釋放及去除晶背微細損傷減少破片。晶背金屬化綠色製程,無化學蝕刻與HF洗淨,Ti/Ni/Ag鍍層簡化製程不易变⾊且具成本優勢。

  • IGBT-BGBM耐高溫製程 SIPOS (Semi-insulation Poly Oxide)、Stoichiometry Silicon Nitride 與抗短路製程 Trench Bottom Implant、 Low temperature Oxidation、 Isolation P-well等關鍵技術。


Wafer thinning process have been developed as specification of less than 50 micro-meter.

Reclaimed wafer developed new process with physical film removal technology. To reducing chemical consumption. To increasing process throughput.

New technology of green cleaning process to saving water and chemical consumption.
